Medical Gas Pipeline System Flowmeter

Piston Type

Oxygen Flowmeter Regular with Humidifier

Technical Specification

Input Pressure
15 Mpa
Output Pressure
0.2-0.3 Mpa
Automatic Discharge Pressure of the Safety Valve
0.32+ 0.5 Mpa
The Flow Range
1-15 LPM, 1-300 LPM, 1-70 LPM (Can be customized according to request)
Cylinder Connection
CGA540, CGA870, Bull Nose, DIN477 (Can be customized according to request)
Regulator Constructure
Piston-type Design
Rotary Control Knob
Adjust easily, no oxygen output when shut off the knob
Humidifier Bottle
200ml Polycarbonate bottle are impact resistant for maximum durability and service life can be soaked and disinfected
308P/H19-15CGA540
308P/H19-15BN
308P/H19-15BN-L
308P/H19-15BNH-L
318P/H6-15CGA540
318P/H6-15BN
318P/H6-15BN-L
318P/H6-15BNH-L
328/H1-15CGA540
328/H1-15BN
328/H1-15BN-L
328P/H1-15BNH-L
Model Number Flow Range Accuracy Inlet Pressure Output Pressure Inlet Connection Pressure Gauge Range
CGA326-M 1-10LPM
1-15LPM
1-30LPM
1-50LPM
1-70LPM
Grade 4 12Mpa
15Mpa
0.2-0.3Mpa 1-10LPM
1-15LPM
1-30LPM
1-50LPM
1-70LPM
G5/8-14/RH
CGA540-RH
G3/4-14-RH
DIN477-6/9
CGA870
3,500 psi / 250 bar
308P/H19-15BN
308P/H19-15BN-L
308P/H19-15BNH-L
318P/H6-15CGA540
318P/H6-15BN
318P/H6-15BN-L
318P/H6-15BNH-L
318P/328/H1-15CGA540
328/H1-15BN
328/H1-15BN-L
328P/H1-15BNH-L

Flowmeter Diaphragm Type

Oxygen Flowmeter Regular with Humidifier

Technical Specification

Input Pressure
15 Mpa
Output Pressure
0.2-0.3 Mpa
Automatic Discharge Pressure of the Safety Valve
0.32+ 0.5 Mpa
The Flow Range
1-15 LPM, 1-300 LPM, 1-70 LPM (Can be customized according to request)
Cylinder Connection
CGA540, CGA870, Bull Nose, DIN477 (Can be customized according to request)
Regulator Constructure
Piston-type Design
Rotary Control Knob
Adjust easily, no oxygen output when shut off the knob
Humidifier Bottle
200ml Polycarbonate bottle are impact resistant for maximum durability and service life can be soaked and disinfected
308D/H19-15CGA540
308D/H19-15BN
308D/H19-15BNH-L
508D/H1-70CGA540
508D/H1-70BN
508D/H1-70BNH-L
808D/H12-15CGA540
808D/H12-15BN
808D/H12-15BNH-L
Model Number Flow Range Accuracy Inlet Pressure Output Pressure Inlet Connection Pressure Gauge Range
308D/H19-15CGA540 1-10LPM
1-15LPM
1-30LPM
1-50LPM
1-70LPM
Grade 4 12Mpa
15Mpa
0.2-0.3Mpa G5/8-14-RH
CGA540-RH
G3/4-14-RH
DIN477-6/-9
CGA870
3,500 psi / 250 bar
308D/H19-15BN
308D/H19-15BNH-L
508D/H1-70CGA540
508D/H1-70BN
508D/H1-70BNH-L
808D/H12-15CGA540
808D/H12-15BN
808D/H12-15BNH-L

Oxygen Flowmeter

With Humidifier

AKM308/H17-JS15
AKM318/H5-JS15
AKM507/H1-OH15
AKM518/H9-DN15
AKM608/H7-SIS15
AKM618/H1-OH15
AKM628/H1-OH15
AKM908/H14-BS15
Model Number Humidifier Optional Inlet Adapter Flow Range Other Accessories
AKM308/H17-JS15 0-1.5LPM
0-3LPM
1-10LPM
1-15LPM
1-30LPM
1-40LPM
1-50LPM
1-70LPM
Grade 4 0.35Mpa 8mm
AKM318/H5-JS15
AKM507/H1-OH15
AKM518/H9-DN15
AKM608/H7-SIS15
AKM618/H1-OH15
AKM628/H1-OH15
AKM908/H14-BS15

Oxygen Flowmeter

With Humidifier

AKM708/H13-DN15
AKM718/H13-OH15
AKM728/H13-FS15
AKM738/H13-OH15
AKM808/H12-DS15
AKM818/H11-OH15
AKM508/H1-DS15-PT
AKM508/H1-JS15-TD
Model Number Humidifier Optional Inlet Adapter Flow Range Other Accessories
AKM708/H13-DN15 0-1.5LPM
0-3LPM
1-10LPM
1-15LPM
1-30LPM
1-40LPM
1-50LPM
1-70LPM
Grade 4 0.35Mpa 8mm
AKM718/H13-OH15
AKM728/H13-FS15
AKM738/H13-OH15
AKM808/H12-DS15
AKM818/H11-OH15
AKM508/H1-DS15-PT
AKM508/H1-JS15-TD

Medical Flowmeter

Technical Specification

Flowmeter Tube
Flow scale line straight and clear, the center line is perpendicular to the tube
Rotary Control Knob
Adjusted easily, no oxygen output when shut off the knob
Inlet Adapter
Different standard adapters available for connecting with the gas outlets
Pressure Relief Valve Automatic
0.4-0.6 Mpa
Humidifier Bottle
Polycarbonate bottle are impact resistant for maximum durability and service life can be soaked and disinfected
Back pressure
compensated and calibrated at 50 psi, calibration pressure at 65 psi is also available
Humidifier Output Connector
8mm dia.
AKM638A-15
AKM638A-15
AKM518-15
AKM648A-15
AKM618-15
AKM658A-15
AKM608-15
AKM628-15
Model Number Humidifier Optional Inlet Adapter Flow Range Other Accessories
AKM638A-15 0-1.5LPM
0-3LPM
1-10LPM
1-15LPM
1-30LPM
1-40LPM
1-50LPM
1-70LPM
Grade 4 0.35Mpa 8mm
AKM318-15
AKM518-15
AKM648A-15
AKM618-15
AKM658A-15
AKM608-15
AKM628-15
